约翰迪尔零件查询410 - BACKHOE, LOADER CLUTCH DISCONNECT AND FLYWHEEL [01E24]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 263 次

Pos.	Part No	Qty	Parts name	Comments
1.	T20088	[1]	Gear	(142 TEETH)
2.	AT18181	[1]	Flywheel	WITH RING GEAR
2.	AR66780	[1]	Flywheel	WITH RING GEAR
3.	AL28037	[1]	Ball Bearing
3.	JD9449	[1]	Ball Bearing
4.	AT21669	[1]	Clutch Disk	(SUB RE33891) DIESEL
4.	RE33891	[1]	Clutch Disk	(SUB FOR AL24059) DIESEL
5.	AT17464	[1]	Thrust Bearing
6.	19H3483	[8]	Cap Screw	3/8" X 1-1/8"
7.	12H304	[8]	Lock Washer	3/8"
8.	AR69708	[1]	Seal	(SUB FOR AF1934R)
9.	T22178	[1]	Washer
10.	T22177	[1]	Support
11A.	T22505	[1]	Fork
11B.	T63651	[1]	Fork
12.	T22567	[2]	Pin Fastener
13A.	AT20055	[1]	Housing	CARRIER FOR THROW OUT BEARING, WITH PINS
13B.	AT60365	[1]	Roller Carriage
14.	L372T	[6]	Cap Screw
15.	12H303	[6]	Lock Washer	5/16"
16.	R27320	[1]	Bushing
17.	T24948	[1]	Spring
18.	34H253	[1]	Spring Pin	1/8" X 1-3/8"
19A.	AT27717	[1]	Shaft
19B.	AT60373	[1]	Shaft
20.	........	[3]	Pin Fastener	( T11700 NO LONGER AVAILABLE)
21.	........	[3]	Lever	( T11701 AND T63652 NO LONGER AVAILABLE)
21.	T63652	[3]	Lever
22.	T13267	[3]	Clip
23.	14H882	[3]	Nut	5/16"
24.	........	[3]	Washer	( T13269 NO LONGER AVAILABLE)
25.	H61022	[3]	Cap Screw
26.	........	[3]	Spring	( T24956 NO LONGER AVAILABLE)
27.	........	[1]	Bracket	( H33689 NO LONGER AVAILABLE)
28.	........	[1]	Clutch Plate	( T24955 NO LONGER AVAILABLE)
29.	AR63785	[1]	Plate	(SUB FOR AT22064) (SUB AT60368)
29.	AT60368	[1]	Clutch Plate
30.	19H3385	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-1/8" (WHEN REPLACING R28029 ORDER (4) 19H3385 AND (4) T23891 THIS APPLICATION)
31A.	19H3483	[2]	Cap Screw	3/8" X 1-1/8"
31B.	H78097	[4]	Screw	(SUB FOR R49482)
