约翰迪尔零件查询410 - BACKHOE, LOADER REVERSER CLUTCH CONTROL VALVE AND PISTON ASSEMBLY [01F07]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 876 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2380	[6]	Screw	1/4" X 1"
2.	24H1286	[6]	Washer	9/32" X 1/2" X 1/16"
3.	R72874	[1]	Gasket	(SUB FOR R39159)
4.	F3366R	[1]	Snap Ring
5.	R72654	[2]	Snap Ring	(SUB FOR R27507)
6.	R31319	[1]	Pin
7.	R39150	[1]	Valve
7.	T39520	[1]	Valve
8.	R39137	[1]	Spring
9.	R39140	[1]	Pin Fastener
10.	R39144	[1]	Housing	(SUB R54579, (2) R27216 AND (2) R26287)
10.	R49255	[1]	Housing	(SUB R54579, (2) R27216 AND (2) R26287)
10.	RE50940	[1]	Housing	(CONTAINS RE46350 HOUSING, R108837 VALVE, R112889 PLUG, R33259 ORING, AND R89476 SPRING) (SUB FOR R54579 ALSO ORDER RE50941 PLATE AND R107207 GASKET) (SUB FOR RE46350)
11.	AR39043	[2]	Seal
12.	R39164	[1]	Plug
13.	R26906	[1]	O-Ring
14.	R33277	[1]	Spring
15.	D2361R	[1]	Ball	1/2"
16.	R39294	[1]	Pin Fastener
17.	F3322R	[1]	Spring
18.	R39133	[1]	Spring
19.	R39229	[1]	Spring
20.	R63364	[1]	Piston	(SUB FOR R39131)
21.	34H310	[1]	Spring Pin	1/4" X 3/4"
22.	R39149	[1]	Valve
23.	R34028	[1]	Bolt
24.	R87627	[1]	O-Ring	(SUB FOR R27976, THIS APPLICATION)
25.	R39158	[1]	Cover	(SUB FOR AR39096)
26.	R26287	[1]	O-Ring
27.	R27216	[1]	Drain Plug	(SUB FOR R31631)
28.	R26287	[1]	O-Ring
29.	R27216	[1]	Drain Plug	(SUB FOR R31631)
30.	T113380	[1]	Pressure Relief Valve	OIL COOLER RELIEF, (SUB FOR R39294 AND T59404)
31.	R27216	[1]	Drain Plug	(WITHOUT REVERSE WARNING ALARM)
32.	R26287	[1]	O-Ring	(WITHOUT REVERSE WARNING ALARM)
