约翰迪尔零件查询410 - BACKHOE, LOADER TRANSMISSION CASE FILTER, OIL CAP, AND PARKING BRAKE PLUGS [01F13]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
302 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T20168
|
[8] |
Washer
|
|
| 2. |
19H2735
|
[2] |
Cap Screw
|
|
| 3. |
R1590R
|
[1] |
Washer
|
|
| 4. |
AT19830
|
[1] |
Dipstick
|
|
| 4. |
T12083
|
[1] |
Plug
|
|
| 5. |
U41438
|
[1] |
Tube
|
|
| 6. |
M4225T
|
[1] |
Plug
|
|
| 7. |
15H562
|
[1] |
Pipe Plug
|
|
| 8. |
T21937
|
[1] |
Plug
|
|
| 9. |
15H584
|
[1] |
Pipe Plug
|
|
| 10. |
R27003
|
[1] |
Washer
|
|
| 11. |
19H2351
|
[1] |
Cap Screw
|
|
| 12. |
R27490
|
[1] |
O-Ring
|
|
| 13. |
T21776
|
[1] |
Screw
|
|
| 14. |
14H971
|
[1] |
Nut
|
|
| 15. |
19H2510
|
[6] |
Cap Screw
|
|
| 16. |
AR26375
|
[1] |
Screen
|
|
| 17. |
A4808R
|
[1] |
Washer
|
|
| 18. |
R40147
|
[1] |
Fitting
|
|
