约翰迪尔零件查询410 - BACKHOE, LOADER TRANSMISSION CASE [01F12]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 223 次

Pos.	Part No	Qty	Parts name	Comments
1.	R39112	[1]	Fitting
2.	R26375	[1]	O-Ring
3.	T26565	[2]	Dowel Pin	(A)
4.	M1102T	[3]	Plug
5.	T17882	[1]	Washer
6.	R26552	[1]	Ball	(A)
7.	R48685	[6]	Dowel Pin	(A) (SUB FOR A120R)
8.	AT23308	[1]	Transmission Case	(MARKED T25400) (CONSISTS OF PARTS MARKED, WITH AN (A)) (SUB AT66704, R56615 COUNTERSHAFT WITH GEAR, JD9878 NEEDLE BEARING AND L29048 SNAP RING)
8.	AT40655	[1]	Transmission Case	(MARKED R55840) (CONSISTS OF ALL PARTS, FOLLOWED BY AN (A)) (ALSO INCLUDES T21562 AND T12083) (SUB AT66704)
8.	AT66704	[1]	Transmission Case	(MARKED T72727 OR T59038) (CONSISTS OF ALL PARTS, FOLLOWED BY AN (A)) (ALSO INCLUDES U41438, T12083 AND M4225T) (SUB FOR AT43407, THIS APPLICATION)
9.	19H2367	[1]	Cap Screw	5/8" X 3/4", (CENTER LINK BRACKETS STUD HOLE)
10.	T18891	[2]	Plug
11.	19H2643	[1]	Cap Screw	1/2" X 7/8"
12.	T22653	[2]	Plug
13.	R26727	[2]	Drain Plug
14.	A4827R	[2]	Washer
15.	T18891	[1]	Plug
16.	15H562	[1]	Pipe Plug	1"
16.	15H629	[1]	Pipe Bushing	1" X 1/4"
17.	19H2351	[1]	Cap Screw	1/2" X 1/2"
18.	R27003	[1]	Washer
19.	T27716	[1]	Compression Spring
20.	R26552	[1]	Ball
21.	T22128	[1]	Bushing	(A)
22.	T24729	[2]	Bushing	(A)
