约翰迪尔零件查询410 - BACKHOE, LOADER PARKING BRAKE LEVER AND LINKAGE [01F15]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 330 次

Pos.	Part No	Qty	Parts name	Comments
1.	T44560	[1]	Plate	BRAKE LATCH
2.	12H301	[2]	Lock Washer	1/2"
3.	21H1253	[2]	Screw	1/2" X 1-1/4"
4.	T21998	[1]	Bushing
5.	T21593	[1]	Pin
6.	........	[1]	Handbrake Lever	( AT43403 NO LONGER AVAILABLE) (ORDER T21593, T21998 AND T44559)
7.	11M7059	[1]	Cotter Pin	3.200 X 20 MM
8.	T21587	[1]	Pawl
9.	11M7077	[1]	Cotter Pin	1.600 X 25 MM
10.	T44561	[1]	Rod
11.	L62606	[1]	Knob	(SUB FOR T21595)
12.	T21576	[1]	Spring
13.	24H1451	[1]	Washer	1-1/32" X 1-3/4" X 0.060"
14.	A602R	[1]	Snap Ring
15.	11M7081	[2]	Cotter Pin	2.500 X 20 MM
16.	T44558	[1]	Lever	OUTER
17.	25H154	[1]	Groove Pin	3/8" X 2"
18.	25H153	[1]	Groove Pin	3/8" X 1-3/4"
19.	T122075	[1]	O-Ring	(SUB FOR U11061, THIS APPLICATION) (SUB FOR U45860)
20.	T67040	[1]	Shaft	(SUB FOR T44557 AND T49572)
21.	26H77	[1]	Shaft Key	3/16" X 3/4"
22.	C1067R	[2]	Pin Fastener	(USE IF AVAILABLE)
22.	R65563	[2]	Pin Fastener	(SUB FOR C1067R)
23.	AT43405	[1]	Rod
24.	19H1820	[2]	Cap Screw	1/2" X 3"
25.	H35925	[1]	Lock Nut
26.	AT43404	[1]	Support	(SUB AT56984)
26.	AT56984	[1]	Support
27A.	T21590	[1]	Lever	(SUB L32144, L56128 AND L29884)
27B.	L32144	[1]	Lever
28.	R1888R	[1]	Strap
29.	19H3483	[1]	Cap Screw	3/8" X 1-1/8"
30.	24H1162	[2]	Washer	17/32" X 1-1/4" X 0.060"
31.	24H1272	[2]	Washer	9/16" X 1-1/4" X 1/4"
32.	T44566	[1]	Stud
33.	14H1040	[2]	Nut	1/2", (SUB FOR 14H809)
34.	H35925	[1]	Lock Nut
34.	14H1039	[1]	Nut	5/8"
35.	12H294	[1]	Lock Washer	5/8"
36.	24H1365	[1]	Washer	21/32" X 1" X 0.090"
37.	T61537	[1]	Support
38.	19H2994	[1]	Cap Screw	HS, SAE 8, 5/8" X 1-1/2"
