约翰迪尔零件查询410 - BACKHOE, LOADER TRANSMISSION TOP COVER (SERIAL NO. -300420) [01F16]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
831 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
L29872
|
[1] |
Plug
|
|
| 2. |
19H2993
|
[10] |
Cap Screw
|
|
| 3. |
19H2735
|
[1] |
Cap Screw
|
|
| 4. |
R41859
|
[1] |
Line
|
|
| 5. |
AT34291
|
[1] |
Dipstick
|
|
| 6. |
19H1930
|
[1] |
Cap Screw
|
|
| 7. |
T34530
|
[1] |
Angle
|
|
| 8. |
28H2642
|
[1] |
Spacer
|
|
| 9. |
19H1868
|
[1] |
Cap Screw
|
|
| 10. |
AT85153
|
[1] |
Switch
|
|
| 10. |
RE38390
|
[1] |
Switch
|
|
| 11. |
T16911
|
[AR] |
Shim
|
|
| 12. |
19H1805
|
[1] |
Cap Screw
|
|
| 13. |
T55423
|
[1] |
Base
|
|
| 14. |
T21641
|
[1] |
Gasket
|
|
| 15. |
R26906
|
[1] |
O-Ring
|
|
| 16. |
R27474
|
[1] |
Drain Plug
|
|
| 17. |
T21564
|
[1] |
Washer
|
|
