约翰迪尔零件查询410 - BACKHOE, LOADER GEAR SHIFTERS AND SHIFTER SHAFTS [01F22]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 442 次

Pos.	Part No	Qty	Parts name	Comments
1.	M1102T	[3]	Plug
2.	34H251	[2]	Spring Pin	1/8" X 1"
3.	T27716	[4]	Compression Spring
4.	R26552	[8]	Ball	5/16"
5.	AR95992	[1]	Shaft	1ST AND 5TH, 2ND AND 6TH SPEED (SUB FOR AT20786, THIS APPLICATION)
6.	T25614	[4]	Set Screw
7.	L28401	[1]	Shifter	1ST AND 5TH, 2ND AND 6TH SPEED, (SUB FOR T21603)
8.	T21604	[1]	Control	(SUB R59032)
8.	R59032	[1]	Shifter	3RD AND 7TH, 4TH AND 8TH SPEED, (SUB FOR T32142)
9.	R98941	[1]	Pin	(SUB FOR T22435)
9.	R98941	[1]	Pin	(SUB FOR R60559)
10.	R60556	[1]	Shifter	LOW AND REVERSE, (SUB FOR T21602)
11.	R59176	[1]	Shifter	HIGH RANGE, (SUB FOR T26197)
12.	AL33250	[1]	Shifter Rod	LOW AND REVERSE, WITH GUIDE, (SUB FOR AT29387)
13.	AT32738	[1]	Shaft	HIGH RANGE, WITH GUIDE
13.	AT68966	[1]	Shaft	HIGH RANGE, WITH GUIDE, (SUB FOR AT53247)
14.	T22736	[1]	Pin Fastener
15.	AR95991	[1]	Shaft	3RD AND 7TH, 4TH AND 8TH SPEED (SUB FOR AT20874, THIS APPLICATION)
16.	400R	[5]	Ball	1/4"
17.	T28680	[1]	Spring
