约翰迪尔零件查询410 - BACKHOE, LOADER TRANSMISSION DRIVE SHAFT ASSEMBLY [01F23]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
243 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
JD7449
|
[1] |
Bearing Cup
|
|
| 2. |
JD7375
|
[1] |
Bearing Cone
|
|
| 3. |
T21980
|
[1] |
Drive Shaft
|
|
| 4. |
JD9839
|
[1] |
Needle Bearing
|
|
| 5. |
R54380
|
[1] |
Dowel Pin
|
|
| 6. |
JD8171
|
[1] |
Bearing Cone
|
|
| 7. |
JD8276
|
[1] |
Bearing Cup
|
|
| 8. |
T21442
|
[AR] |
Shim
|
|
| 8. |
T21443
|
[AR] |
Shim
|
|
| 8. |
T21444
|
[AR] |
Shim
|
|
| 9. |
H246R
|
[3] |
Strap
|
|
| 10. |
T22984
|
[1] |
Cap Screw
|
|
| 11A. |
R67336
|
[1] |
Shift Collar
|
|
| 11B. |
R69917
|
[1] |
Shift Collar
|
|
| 12A. |
........
|
[1] |
Bearing Housing W/O Bearing
|
|
| 12B. |
R69918
|
[1] |
Bearing Housing W/O Bearing
|
|
| 13. |
19H2633
|
[1] |
Cap Screw
|
|
| 14. |
19H3239
|
[1] |
Cap Screw
|
|
