Pos.	Part No	Qty	Parts name	Comments
1.	T30254	[8]	Rivet	7/16" X 1-11/16"
1.	T152922	[8]	Rivet	1/2" X 1 5/8"
2.	JD8997	[1]	Bearing Cone
3.	JD8255	[1]	Bearing Cup
4.	T31792	[AR]	Shim	0.05 MM (.002")
4.	T31793	[AR]	Shim	0.13 MM (.005")
4.	T31794	[AR]	Shim	0.25 MM (.010") (SUB FOR T17201)
5.	T21975	[1]	Gear	1ST AND 5TH SPEED, (40 TEETH)
6.	T21970	[2]	Shift Collar
7.	T21964	[2]	Sleeve
8.	T21976	[1]	Gear	2ND AND 6TH SPEED, (36 TEETH)
9.	T21977	[1]	Gear	4TH AND 8TH SPEED, (27 TEETH)
10.	AT19966	[1]	Gear	3RD AND 7TH SPEED WITH BUSHING, (MARKED T21979) (31 TEETH)
11.	L32843	[1]	Nut	(SUB FOR T24917)
12.	T24918	[1]	Washer
13.	JD8979	[1]	Bearing Cone
14.	JD8267	[1]	Bearing Cup
15.	........	[2]	Shim	(A) ( M2056T NO LONGER AVAILABLE) 0.05 MM (.002")
15.	........	[3]	Shim	(A) ( M2057T NO LONGER AVAILABLE) 0.13 MM (.005")
15.	........	[3]	Shim	(A) ( M2058T NO LONGER AVAILABLE) 0.25 MM (.010")
16.	T21965	[1]	Washer
17.	R55721	[2]	Thrust Washer	(SUB FOR T24730, THIS APPLICATION)
18.	R56473	[1]	Thrust Washer	(SUB FOR T24734)
19.	R55722	[1]	Thrust Washer	(SUB FOR T24731, THIS APPLICATION)
20.	T30253	[1]	Housing	(ALSO ORDER (8) T30254)
20.	T149743	[1]	Housing	(ALSO ORDER (8) T152922)
21.	AT21622	[1]	Differential	(CONTAINS T30253 AND (8) T30254) HOUSING, R.H. (MARKED T30253), WITH GEAR, RING (MARKED T21401) (35 TEETH), AND PINION, BEVEL (MARKED T21402) (8 TEETH)
