约翰迪尔零件查询410 - BACKHOE, LOADER COUNTERSHAFT AND BEARING SUPPORT [01F24]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 904 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD9822	[1]	Needle Bearing
1.	JD9878	[1]	Needle Bearing
2.	R34399	[1]	Snap Ring
2.	L29048	[1]	Snap Ring
3.	T19242	[1]	Snap Ring
4.	T19245	[1]	Washer
5.	T21978	[1]	Gear	(SUB T30065) (22 TEETH) (LOW RANGE)
5.	T30065	[1]	Gear	(22 TEETH) (LOW RANGE)
6.	T21964	[1]	Sleeve
7.	R55721	[1]	Thrust Washer	(SUB FOR T24730, THIS APPICATION)
8.	T21970	[1]	Shift Collar
9.	R65576	[1]	Gear	(SUB FOR T24728) (SUB R67341) (12 TEETH)
9.	R67341	[1]	Gear	(12 TEETH)
10.	T24729	[2]	Bushing
11.	R57696	[2]	Washer	(SUB FOR R1870R)
12.	19H3065	[2]	Cap Screw	3/8" X 2"
13.	T24736	[1]	Clamp
14.	19H3239	[1]	Cap Screw	3/8" X 1-1/4"
15.	19H2676	[1]	Cap Screw	3/8" X 1"
16.	JD7672	[1]	Ball Bearing
17.	T24737	[1]	Snap Ring
18.	A364R	[1]	Snap Ring
19.	B1402R	[1]	Snap Ring	(SUB FOR F215R)
20.	B190R	[1]	Snap Ring
21.	JD9258	[1]	Ball Bearing	(SUB FOR JD9465)
22.	T21969	[2]	Friction Plug
23.	T24732	[2]	Spring
24.	T24521	[2]	Disk	(WITH REVERSER)
25.	L36557	[1]	Bearing Housing W/O Bearing	(SUB FOR T24691, THIS APPLICATION)
26.	T16573	[1]	Pin
27.	T24726	[1]	Countershaft	(37 TEETH) (WITH GEAR)
27.	R56615	[1]	Countershaft	(37 TEETH) (WITH GEAR)
