| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T35794 | [1] | Shaft | (SUB T38554 SHAFT AND T38555 WASHER) |
| 1. | T38554 | [1] | Spindle | |
| 1. | T152651 | [1] | Spindle | (SUB FOR T59425) |
| 2. | AT20703 | [1] | Seal | OUTER |
| 3. | L35542 | [1] | Guide | (SUB FOR T21429) |
| 4. | JD8946 | [1] | Bearing Cone | OUTER |
| 5. | JD8206 | [2] | Bearing Cup | |
| 6. | JD7781 | [1] | Lubrication Fitting | 1/8" (SUB FOR JD7759, THIS APPLICATION) |
| 7. | R27216 | [1] | Drain Plug | (SUB FOR R31631) |
| 8. | R26287 | [1] | O-Ring | |
| 9. | 19H1805 | [12] | Cap Screw | 1/2" X 2-1/4", (WITHOUT PARKING BRAKE AND WITH REAR EXHAUST) |
| 9. | 19H1805 | [10] | Cap Screw | 1/2" X 2-1/4", (WITH PARKING BRAKE) |
| 10. | R21612 | [1] | Bleed Valve | |
| 11. | AT34775 | [1] | Housing | (INCLUDES HOUSING MARKED T35790 AND GEAR MARKED T21410) (ALSO ORDER (3) T21428 DOWEL PINS AND (3) R36666 DOWEL PINS) |
| 11. | AT74432 | [1] | Housing | (INCLUDES HOUSING MARKED T76229 AND GEAR MARKED R57200) (SUB FOR AT40757 MARKED T41733 AND GEAR MAKRED R57200) (SUB AT106669, R27216 AND R26287, THIS APPLICATION) |
| 11. | AT169364 | [1] | Housing | (MARKED T105800 AND GEAR MARKED R57200 OR T125844) (SUB FOR AT101717, MARKED T105800 AND GEAR MARKED R57200, AND FOR AT106669 MARKED T105800 AND GEAR MARKED R57200 OR T125844) |
| 11. | T151158 | [1] | Ring Gear | (MARKED R57200) (USE WITH AT106669) (SUB FOR T125844) (NOT ILLUSTRATED) |
| 12. | R26198 | [3] | Dowel Pin | |
| 13. | R98915 | [1] | Gasket | (SUB FOR T21419) |
| 14. | AT124396 | [1] | Seal | INNER, (SUB FOR AT16887) |
| 15. | JD8151 | [1] | Bearing Cone | INNER (SUB FOR JD8992, THIS APPLICATION) |
| 16. | T21428 | [3] | Dowel Pin | AXLE HOUSING PILOT |
| 17. | R47862 | [1] | Cap |
