约翰迪尔零件查询410 - BACKHOE, LOADER PLANETARY PINION CARRIER [01G04]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 536 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[3]	Pinion Shaft	( T38049 NO LONGER AVAILABLE)
1.	T149083	[3]	Shaft	(SUB FOR T38049)
2.	T141566	[6]	Thrust Washer	(SUB FOR T21424)
3.	T21547	[3]	Gear	(18 TEETH)
4.	T21418	[69]	Pin
5.	T35791	[1]	Snap Ring
6.	T35792	[1]	Planet Pinion Carrier	(SUB T38506)
6.	T38506	[1]	Planet Pinion Carrier	(USE IF AVAILABLE)
6.	........	[1]	Planet Pinion Carrier	( T133114 NO LONGER USED) (SUB FOR T38506)
6.	T149082	[1]	Planet Pinion Carrier	(SUB FOR T133114)
7.	T38555	[1]	Washer	(SUB FOR T35795)
8.	T35306	[1]	Screw
9.	T35305	[1]	Lock Plate	(SUB T55419)
9.	T55419	[1]	Lock Plate	(A)
10.	T28908	[1]	Drive Shaft	L.H. (SUB T71926)
10.	T71926	[1]	Drive Shaft	L.H.
10.	T28907	[1]	Drive Shaft	R.H. (SUB T71925)
10.	T71925	[1]	Drive Shaft	R.H.
11.	T38475	[1]	Shim	.20 MM (.008")
12.	T55420	[1]	Washer	(A)
13.	........	[AR]	Shim	(A) ( M2054T NO LONGER AVAILABLE) (SUB AT146274) 0.13 MM (.005")
13.	........	[AR]	Shim	(A) ( M2055T NO LONGER AVAILABLE) (SUB AT146274) 0.25 MM (.010")
...	AT53249	[1]	Kit	REAR AXLE SHIM
