约翰迪尔零件查询410 - BACKHOE, LOADER POWER STEERING ARM AND DRAG LINK (SERIAL NO. -235785) [01G10]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
417 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3239
|
[6] |
Cap Screw
|
|
| 2. |
12H304
|
[6] |
Lock Washer
|
|
| 3. |
AT20854
|
[1] |
Cover
|
|
| 3. |
AT54954
|
[1] |
Cover
|
|
| 4. |
T21445
|
[1] |
Bushing
|
|
| 5. |
T21527
|
[1] |
Gasket
|
|
| 6. |
T21722
|
[1] |
Pin
|
|
| 7. |
19H1227
|
[1] |
Cap Screw
|
|
| 8. |
12H297
|
[1] |
Lock Washer
|
|
| 9. |
T21659
|
[1] |
Plate
|
|
| 10. |
T34254
|
[1] |
Shaft
|
|
| 11. |
AN70540
|
[1] |
Seal
|
|
| 12. |
T54367
|
[1] |
Lever
|
|
| 13. |
R20135
|
[1] |
Washer
|
|
| 13. |
T42971
|
[1] |
Bushing
|
|
| 14. |
19H1833
|
[1] |
Cap Screw
|
|
| 14. |
19H2710
|
[1] |
Cap Screw
|
|
| 15. |
AT33297
|
[1] |
Drag Link
|
|
| 16. |
24H1369
|
[1] |
Washer
|
|
| 17. |
14H918
|
[2] |
Nut
|
|
| 18. |
11M7083
|
[2] |
Cotter Pin
|
|
