约翰迪尔零件查询410 - BACKHOE, LOADER POWER STEERING VALVE (SERIAL NO. 292511-389960) [01G15]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
280 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
C15104
|
[1] |
Seal
|
|
| 2. |
T54324
|
[1] |
Snap Ring
|
|
| 3. |
T54323
|
[1] |
Isolator
|
|
| 4. |
C15107
|
[1] |
O-Ring
|
|
| 5. |
B3690R
|
[1] |
O-Ring
|
|
| 6. |
T41836
|
[2] |
Thrust Bearing Race
|
|
| 7. |
JD8856
|
[1] |
Needle Bearing
|
|
| 8. |
........
|
[6] |
Spring
|
|
| 9. |
........
|
[1] |
Housing
|
|
| 10. |
M4124T
|
[1] |
Dowel Pin
|
|
| 11. |
........
|
[1] |
Valve
|
|
| 12. |
........
|
[1] |
Sleeve
|
|
| 13. |
AT61101
|
[1] |
Housing
|
|
| 14. |
T64311
|
[1] |
Retainer
|
|
| 15. |
R26552
|
[1] |
Ball
|
|
| 16. |
R10093
|
[1] |
O-Ring
|
|
| 17. |
T64312
|
[1] |
Seat
|
|
| 18. |
A3917R
|
[1] |
O-Ring
|
|
| 19. |
T64313
|
[1] |
Set Screw
|
|
| 20. |
T37253
|
[1] |
Drive
|
|
| 21. |
T64309
|
[1] |
Spacer
|
|
| 22. |
N170851
|
[3] |
O-Ring
|
|
| 22. |
T70321
|
[3] |
Washer
|
|
| 23. |
T64310
|
[1] |
Washer
|
|
| 24. |
AT61100
|
[1] |
Gear
|
|
| 25. |
T64308
|
[1] |
Cap
|
|
| 26. |
E58090
|
[7] |
Screw
|
|
| 27. |
AT61099
|
[1] |
Valve
|
|
