约翰迪尔零件查询410 - BACKHOE, LOADER POWER STEERING CYLINDER (SERIAL NO. 235786-343922) [01G18]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
739 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T48206
|
[1] |
Bushing
|
|
| 2. |
AT46776
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 3. |
M2023T
|
[1] |
Lock Nut
|
|
| 4. |
T48219
|
[1] |
Washer
|
|
| 5. |
H84318
|
[1] |
O-Ring
|
|
| 6. |
T48218
|
[1] |
Wear Ring
|
|
| 7. |
T48217
|
[1] |
Piston
|
|
| 8. |
R30319
|
[1] |
O-Ring
|
|
| 9. |
R81188
|
[1] |
Back-Up Ring
|
|
| 10. |
R80905
|
[1] |
Guide
|
|
| 11. |
T48212
|
[1] |
Seal
|
|
| 12. |
T48211
|
[1] |
Seal
|
|
| 13. |
22H1077
|
[1] |
Set Screw
|
|
| 14. |
JD7788
|
[1] |
Lubrication Fitting
|
|
| 15. |
T48203
|
[1] |
Bushing
|
|
| 16. |
AT46775
|
[1] |
Hydraulic Cylinder Rod
|
|
| 17. |
JD7806
|
[1] |
Lubrication Fitting
|
|
| ... |
........
|
[2] |
Cylinder
|
|
| ... |
RE19219
|
[1] |
Hydraulic Cylinder Kit
|
|
