现代零件查询25/30LC-7M OUTER PANEL 2EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
834 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
71HA-10012
|
[1] |
BONNET ASSY
|
|
| 1-1. |
71HA-10021
|
[1] |
BONNET WA
|
|
| 1-2. |
71HA-10111
|
[1] |
SPONGE
|
|
| 1-3. |
71EM-51580
|
[18] |
CAP-STUD BOLT
|
|
| 1-4. |
71FA-10220
|
[2] |
RUBBER-HOOD SUPPORT
|
|
| 1-5. |
71HA-10170
|
[1] |
WEATHER STRIP
|
|
| 7. |
S661-120300
|
[4] |
CAP-RUBBER
|
|
| 10. |
71HF-10512
|
[1] |
COVER-LH
|
|
| 10-1. |
71HF-10570
|
[1] |
COVER-LH
|
|
| 10-2. |
71EM-51571
|
[1] |
HOLDER-ROD
|
|
| 10-3. |
FAC0700770
|
[2] |
GROMMET
|
|
| 10-4. |
S131-051046
|
[2] |
SCREW-W/WASHER
|
|
| 11. |
71HF-10522
|
[1] |
COVER-RH
|
|
| 11-1. |
71HF-10580
|
[1] |
COVER-RH
|
|
| 11-2. |
71EM-51571
|
[1] |
HOLDER-ROD
|
|
| 11-3. |
FAC0700770
|
[2] |
GROMMET
|
|
| 11-4. |
S131-051046
|
[2] |
SCREW-W/WASHER
|
|
| 12. |
71HC-10531
|
[1] |
SUB BONNET-FR
|
|
| 14. |
71HA-10161
|
[2] |
HINGE
|
|
| 18. |
S109-080256
|
[4] |
BOLT-SOCKET
|
|
| 19. |
71FE-10170
|
[4] |
WASHER-RUBBER
|
|
| 20. |
FAC0700820-01
|
[4] |
KNOB
|
|
| 21. |
71HC-10541
|
[1] |
SUB BONNET ASSY-RR
|
|
| 22. |
S035-082026
|
[4] |
BOLT-W/WASHER
|
|
| 23. |
71HA-10610
|
[1] |
HINGE
|
|
| 24. |
71HA-10620
|
[1] |
STRIKER
|
|
| 25. |
71HA-10630
|
[1] |
SHIM(2.0T)
|
|
| 26. |
71HA-10640
|
[1] |
SHIM(4.0T)
|
|
| 28. |
71FG-10070
|
[1] |
GAS SPRING
|
|
| 29. |
S681-230800
|
[1] |
GROMMET
|
|
| 30. |
FHC0904100
|
[1] |
RUBBER-STAY
|
|
| 32. |
S035-082526
|
[2] |
BOLT-W/WASHER
|
|
| 37. |
S461-200152
|
[2] |
PIN-SPLIT
|
|
| 38. |
S403-08200B
|
[6] |
WASHER-PLAIN
|
|
| 38. |
S403-08200B
|
[4] |
WASHER-PLAIN
|
|
| 38. |
S403-08200B
|
[6] |
WASHER-PLAIN
|
|
| 38. |
S403-08200B
|
[4] |
WASHER-PLAIN
|
|
| 39. |
S491-120502
|
[2] |
PIN-CLEVIS
|
|
| 40. |
S501-120002
|
[2] |
PIN-SELF LOCKING
|
|
| 41. |
S403-12100B
|
[2] |
WASHER-PLAIN
|
|
| 42. |
S275-08000B
|
[4] |
NUT-SELF LOCKING
|
|
| 43. |
71HA-10700
|
[1] |
TRAY
|
|
