现代零件查询25/30LC-7M SEATEPC Hyundai

广数供应链运营团队, 16 02月, 2025，浏览： 989 次

Pos.	Part No	Qty	Parts name	Comments
11.	71FG-10521	[1]	SEAT ASSY(PKT)	W/O OPSS
11.	71FG-10531	[1]	SEAT ASSY(PKT+BT)	W/O OPSS
11.	71FG-10541	[1]	SEAT ASSY(PKT+BT+AR)	W/O OPSS
11.	71FG-10551	[1]	SEAT ASSY(PKT+BT+HR)	W/O OPSS
11.	71FH-10511	[1]	SEAT ASSY(PKT)	W/ OPSS
11.	71FH-10521	[1]	SEAT ASSY(PKT+BT)	W/ OPSS
11.	71FH-10531	[1]	SEAT ASSY(PKT+BT+HR)	W/ OPSS
11.	71FH-10541	[1]	SEAT ASSY(PKT+BT+AR)	W/ OPSS
11-A.	310006540	[1]	SWITCH-SEAT	W/ OPSS
11-B.	B51800050	[1]	HARNESS-SEAT	W/ OPSS
11-1.	H31013-100C	[1]	CUSHION ASSY
11-2.	H31013-200B	[1]	BACK ASSY
11-3.	H31013-360	[1]	SHOCK ABSORBER ASSY
11-4.	H31013-600B	[1]	SLIDE TRACK ASSY
11-5.	89890-8A610	[1]	BELT-SEAT	WITH BELT
11-6.	H31023-300G	[1]	SUSPENSION-B	W/O OPSS
11-7.	H31023-301G	[1]	SUSPENSION	WITH OPSS
11-8.	H31010-500	[1]	ARM RESTRAINT-LH	WITH ARM-REST
11-9.	H31015-500	[1]	ARM RESTRAINT-RH	WITH ARM-REST
11-10.	H31010-700	[1]	HIP RESTRAINT-LH	WITH ARM-REST
11-11.	H31015-700	[1]	HIP RESTRAINT-RH	WITH ARM-REST
11-12.	71FH-10590	[1]	KNOB-RECLINER
18.	S109-080256	[4]	BOLT-SOCKET	25LC-7M,OPT SEA
18.	S109-080256	[4]	BOLT-SOCKET	30LC-7M,OPT SEA
38.	S403-08200B	[4]	WASHER-PLAIN	25LC-7M,OPT SEA
38.	S403-08200B	[4]	WASHER-PLAIN	30LC-7M,OPT SEA
42.	S275-08000B	[4]	NUT-SELF LOCKING	25LC-7M,OPT SEA
42.	S275-08000B	[4]	NUT-SELF LOCKING	30LC-7M,OPT SEA
