约翰迪尔零件查询410 - BACKHOE, LOADER HYDRAULIC OIL FILTER AND RELIEF VALVE [01H24]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 671 次

Pos.	Part No	Qty	Parts name	Comments
1.	A4808R	[2]	Washer
2.	T22964	[2]	Fitting
2.	T38460	[2]	Fitting
3.	AR21839	[4]	Clamp	(SUB FOR H2742B, THIS APPLICATION)
4.	........	[1]	Hose	19 MM X 86 MM (3/4" X 3-3/8") (MAKE FROM T61939) (SUB FOR T35688, T35694 AND T21371)
4.	........	[1]	Hose	25 MM X 80 MM (1" X 3-1/8") (MAKE FROM U11186) (SUB FOR T38461 AND T37798)
5.	AT33916	[1]	Elbow Fitting
6.	U12547	[4]	O-Ring	(A) (SUB FOR (4) F3171R)
7.	R27175	[2]	Drain Plug
8.	........	[1]	Hose	25 MM X 76 MM (1" X 3") (MAKE FROM U11186) (SUB FOR T35691 AND T37798)
9.	R39798	[1]	Cover	(SUB R51654)
9.	R51654	[1]	Cover
10.	R394R	[1]	O-Ring
11.	R39799	[1]	Screw	(SUB R82731)
11.	R82731	[1]	Screw	(SUB FOR R54753)
12.	R66064	[1]	Spring	(SUB FOR R1769R, THIS APPLICATION)
13.	24H1227	[1]	Washer	17/32" X 13/16" X 0.060"
14.	R28593	[1]	Retainer	(USE WITH R394R ROUND CROSS-SECTION O-RING) (SUB R65892 AND F2741R)
14.	R65892	[1]	Retainer	(USE WITH F2741R SQUARE CROSS-SECTION O-RING)
15.	R32507	[1]	Snap Ring
16.	AR75603	[1]	Filter Element	(SUB FOR AT34670 AND AR75601)
17.	R34733	[1]	Washer	FILTER COVER TO RELIEF VALVE HOUSING
18.	R26906	[1]	O-Ring	(A)
19.	T27992	[1]	Spring	(A)
20.	R33162	[1]	Valve	(SUB R57559 AND R33259)
20.	R57559	[1]	Valve	(A)
21.	AT26172	[1]	Plug	(A) (NO LONGER AVAILABLE, ORDER R27474 AND T22850)
22.	AT27078	[1]	Housing	(A) (MARKED T27991)
23.	R40976	[1]	Valve	(A)
24.	R30776	[1]	Spring	(A)
25.	AT26171	[1]	Plug	(A)
26.	24M7096	[2]	Washer	0.413" X 0.709" X 0.063"
27.	12H304	[2]	Lock Washer	3/8"
28.	19H3239	[2]	Cap Screw	3/8" X 1-1/4"
29.	R33259	[1]	O-Ring	(A)
30.	R394R	[1]	O-Ring	(USE WITH R28593 RETAINER)
30.	R2741R	[1]	Rod	(USE WITH R65892 RETAINER)
...	AT26173	[1]	Housing
