约翰迪尔零件查询410 - BACKHOE, LOADER HYDRAULIC PUMP OIL PRESSURE LINES [01H25]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 860 次

Pos.	Part No	Qty	Parts name	Comments
1A.	AT34784	[1]	Hydraulic Hose - Fabricate	9/16" X 508 MM (20") X 9/16"
1B.	AT54133	[1]	Hydraulic Hose - Fabricate	9/16" X 635 MM (25") X 9/16", ACCUMULATOR TEE TO STEERING VALVE HOUSING, (SUB FOR AT38635, THIS APPLICATION)
1B.	AT62085	[1]	Hydraulic Hose - Fabricate	9/16" X 1 067 MM (42") X 9/16", (SUB FOR AT39448 AND AT54858)
2A.	AT24371	[1]	Tee Fitting
2B.	AR32665	[1]	Tee Fitting
3.	R26375	[1]	O-Ring
4A.	AT50246	[1]	Hydraulic Hose - Fabricate	3/4" X 455 MM (18") X 3/4", PUMP PRESSURE LINE TEE TO ACCUMULATOR, (SUB FOR AT35193)
4B.	AT38634	[1]	Hydraulic Hose - Fabricate	3/4" X 305 MM (12") X 3/4", PUMP PRESSURE LINE TO ACCUMULATOR
5.	AT85136	[1]	Oil Line	FRONT PRESSURE, (SUB FOR AT33912)
6.	R26906	[1]	O-Ring
7.	R62337	[1]	Fitting	(SUB FOR T34882)
8.	AT33922	[1]	Elbow Fitting
9.	T34889	[1]	Tee Fitting
10.	AT85137	[1]	Oil Line	REAR PRESSURE, (SUB FOR AT33920)
11.	19H118	[1]	Cap Screw	5/16" X 1"
12.	12H303	[1]	Lock Washer	5/16"
13.	R43475	[2]	Clamp
14.	T16172	[1]	Spacer
15.	14H785	[1]	Nut	5/16"
16.	T34887	[1]	Adapter Fitting
17.	U12547	[1]	O-Ring	(SUB FOR F3171R)
