约翰迪尔零件查询410 - BACKHOE, LOADER FRONT AXLE, SPINDLE AND KNUCKLE ASSEMBLY (SERIAL NO. 235786- ) [01I08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 348 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1439	[2]	Cap Screw	5/8" X 3"
2.	12H294	[2]	Lock Washer	5/8"
3.	R20135	[2]	Washer
4.	R52383	[4]	Thrust Washer
5.	T54442	[1]	Arm	(SUB AT46786 TIE ROD, T66938 AND T66939)
5.	T66938	[1]	Steering Arm	R.H. (SUB FOR T56516) (SUB T77482 AND AT76136 AS REQUIRED)
5.	T71745	[1]	Lever	R.H. (SUB T77482 AND AT76136 AS REQUIRED)
5.	T77482	[1]	Steering Arm	R.H. (ALSO ORDER AT76136 AS REQUIRED)
5.	T54443	[1]	Arm	(SUB AT46786 TIE ROD, T66938 AND T66939)
5.	T66939	[1]	Steering Arm	L.H. (SUB FOR T56517) (SUB T77483 AND AT76136 AS REQUIRED)
5.	T71746	[1]	Steering Arm	L.H. (SUB T77483 AND AT76136 AS REQUIRED)
5.	T77483	[1]	Steering Arm	L.H. (ALSO ORDER AT76136 AS REQUIRED)
6.	R30398	[4]	Washer
6A.	R30398	[4]	Washer	(USE WITH AT63364)
6B.	R30398	[2]	Washer	(USE WITH AT74162)
7.	JD7799	[1]	Lubrication Fitting	1/8"
8.	T162396	[2]	Lubrication Fitting	(SUB FOR JD7798) 1/8", STRAIGHT
9.	T23170	[1]	Bushing
10.	R52188	[4]	Bushing
11.	11M7030	[1]	Cotter Pin	5 X 40 MM
12.	14H534	[1]	Nut	3/4", (USE WITH AT30796 AND AT46780) (SUB FOR 14H902)
12.	14M7519	[1]	Nut	M24, (USE WITH AT76138)
13.	T25922	[2]	Washer	(USE IF AVAILABLE)
13.	T151797	[2]	Washer	(SUB FOR T25922 OR T134960)
14.	T21669	[1]	Bushing
15.	T25921	[6]	Shim	.38 MM (.015")
16.	T25840	[1]	Cap Screw
17.	34H308	[3]	Spring Pin	1/4" X 1/2", (USE WITH AT63364)
17.	R56457	[1]	Dowel Pin	1/4" X 0.610", (USE WITH AT74162)
18.	AT46779	[1]	Front Axle	(MARKED T48227) (SUB AT63364)
18.	AT63364	[1]	Front Axle	(MARKED T66813)
18.	AT74162	[1]	Front Axle	(MARKED T76023)
19.	AT46780	[2]	Knuckle	(SUB AT76138, ALSO ORDER AT76136 AS REQUIRED) (USE 14H534 NUT)
19.	AT76138	[2]	Knuckle	(ALSO ORDER AT76136 AS REQUIRED) (USE 14M7519 NUT)
20.	T48225	[2]	Pin Fastener
21.	11M7087	[2]	Cotter Pin	4 X 40 MM
22.	T76024	[2]	Thrust Washer	(USE WITH AT74162)
23.	24H448	[1]	Washer	25/32" X 1-1/8" X 0.090"
