约翰迪尔零件查询410 - BACKHOE, LOADER TIE ROD ASSEMBLY (SERIAL NO. 235786- ) [01I10]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 964 次

Pos.	Part No	Qty	Parts name	Comments
1.	14H918	[2]	Nut	5/8"
2.	R40589	[2]	Cover
2.	R21101	[2]	Cover	(E)
3.	AR27430	[1]	Tie Rod End	(A) OUTER
3.	AT65092	[1]	Tie Rod End	(E) OUTER, (SUB FOR AT58697) (SUB FOR AR74132, THIS APPLICATION)
3.	AT65092	[1]	Tie Rod End	OUTER
4.	19H2698	[2]	Cap Screw	(A) 7/16" X 2"
4.	19H1805	[2]	Cap Screw	(E) 1/2" X 2-1/4"
5.	........	[1]	Tube	(A) (SUB AT46781)
5.	T48226	[1]	Tube	(E)
6.	R28023	[2]	Clamp	(A)
6.	M2301T	[2]	Clamp	(E)
7.	AR27351	[1]	Ball Joint	(A) INNER
7.	AT65091	[1]	Tie Rod End	(E) (SUB FOR AT58696) INNER (SUB FOR AR74131) THIS APPLICATION)
7.	AT65091	[1]	Tie Rod End	INNER
8.	12H293	[2]	Lock Washer	(A) 7/16"
8.	12H301	[2]	Lock Washer	(E) 1/2"
9.	14H813	[2]	Nut	(A) 7/16"
9.	14H1040	[2]	Nut	(E) 1/2", (SUB FOR 14H809)
10.	11M7015	[2]	Cotter Pin	3.200 X 25 MM
11.	24H1365	[2]	Washer	21/32" X 1" X 0.090"
...	AT46781	[1]	Tie Rod Assembly
...	AT63365	[1]	Tie Rod Assembly	(SUB FOR AT46786)
...	AT63365	[1]	Tie Rod Assembly
