约翰迪尔零件查询410 - BACKHOE, LOADER BRAKE VALVE AND OIL LINES (SERIAL NO. 146710- ) [01I13]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 772 次

Pos.	Part No	Qty	Parts name	Comments
1.	R26287	[3]	O-Ring
2.	AT32335	[3]	Elbow Fitting	(SUB FOR AR26746)
3.	AT37333	[1]	Brake Line	(A) L.H. (SUB AT41227)
3.	........	[1]	Oil Line	(B) L.H. (SUB AT41227)
4.	19H1648	[2]	Cap Screw	3/8" X 3/4"
5.	12H304	[2]	Lock Washer	3/8"
6.	R27528	[2]	Clamp
7.	T30367	[1]	Clamp
8.	24H1304	[2]	Washer	13/32" X 23/32" X 0.120"
8.	24H1304	[2]	Washer	13/32" X 23/32" X 0.120"
9.	AR35223	[1]	Elbow Fitting	(A) (B)
10.	R26287	[1]	O-Ring	(A) (B)
11.	T21813	[2]	Seat
12.	U12547	[2]	O-Ring	(SUB FOR (2) F3171R)
13.	T21814	[2]	Compression Spring
14.	400R	[2]	Ball	1/4"
15.	T21815	[2]	Retainer
16.	15H560	[1]	Pipe Plug	1/16"
17.	AR53493	[2]	Housing
18.	........	[2]	Piston	(C) R73933 NO LONGER AVAILABLE, (SUB FOR T22100, THIS APPLICATION) (SUB AT184434)
19.	T21817	[2]	Spring
20.	19H1936	[1]	Cap Screw	3/8" X 3/4"
21.	R27528	[1]	Clamp
22.	T38500	[1]	Angle
23.	12H304	[1]	Lock Washer	3/8"
24.	14H812	[1]	Nut	3/8"
25.	AT32723	[1]	Brake Line	(SUB AT41224)
25.	AT41224	[1]	Line	R.H.
...	AT39633	[1]	Kit	(SUB AT41227) LINE BRAKE OIL, L.H.
...	AT41227	[1]	Kit	LINE BRAKE OIL, L.H.
