约翰迪尔零件查询410 - BACKHOE, LOADER CAB [02B14]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 156 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[4]	Isolator	(MAKE FROM T71383) (SUB FOR U43032)
2.	T37618	[1]	Windowpane
3.	T37619	[1]	Windshield
4.	........	[1]	Frame	( AT36378)
4.	AT42732	[1]	Frame	(SUB FOR AT36929)
4.	AT55599	[1]	Frame
5.	19H2367	[2]	Cap Screw	5/8" X 3/4"
6.	14H1040	[4]	Nut	1/2", (SUB FOR 14H809)
7.	12H301	[4]	Lock Washer	1/2"
8.	24H1162	[4]	Washer	17/32" X 1-1/4" X .060"
9.	24H1254	[AR]	Washer	17/32" X 1-1/8" X 0.105"
10.	24H1272	[AR]	Washer	9/16" X 1-1/4" X 1/4"
11.	19H3586	[AR]	Cap Screw	1/2" X 4-1/4"
11.	19H1805	[AR]	Cap Screw	1/2" X 2-1/4"
11.	19H1781	[AR]	Cap Screw	1/2" X 3-1/2"
12.	R46273	[1]	Plate
13.	21H1302	[2]	Screw	1/4" X 5/8"
14.	19H3065	[4]	Cap Screw	3/8" X 2"
15.	24H1682	[8]	Washer	13/32" X 7/8" X 0.120"
16.	24H1305	[AR]	Washer	13/32" X 13/16" X 0.065"
16.	24H1781	[4]	Washer	13/32" X 7/8" X 1/4"
17.	12H304	[4]	Lock Washer	3/8"
18.	14H812	[4]	Nut	3/8"
19.	T37624	[8]	Seal
20.	T37621	[2]	Seal
21.	T37617	[1]	Windowpane	(L.H. SIDE)
21.	T37617	[1]	Windowpane	(R.H. SIDE)
21.	T38246	[1]	Windowpane	(R.H. SIDE)
22.	AT57848	[1]	Kit	(KIT CONTAINS ONE LATCH, ONE HOOK AND ONE BUMPER PAD) (SUB FOR AT36636, T37932 AND T37933)
23.	21H1193	[4]	Screw	0.190" X 5/8"
24.	14H786	[10]	Nut	1/4"
25.	12H302	[10]	Lock Washer	1/4"
26.	24H1266	[16]	Washer	1-9/32" X 1-3/4" X 0.060"
27.	19H1919	[10]	Cap Screw	1/4" X 5/8"
28.	........	[1]	Partition	LEFT ( AT36362 USE IF AVAILABLE)
28.	AT36364	[1]	Panel	RIGHT
29.	T38245	[1]	Panel	(SUB FOR AT36363)
30.	T37620	[2]	Seal
31.	........	[2]	Plug	( H23126 NO LONGER AVAILABLE)
32.	T15005	[2]	Plug
33.	24H1283	[4]	Washer	7/32" X 1/2" X 0.049"
34.	12H246	[4]	Lock Washer	0.190"
35.	14H778	[4]	Nut	0.190"
36.	T43876	[2]	Reinforcement
37.	T13911	[2]	Plug
...	AT42733	[1]	Cab	(INCLUDES ALL PARTS ON THIS PAGE AND PAGES 60-10, 60-11, 65-5, 65-5A, AND ALL PARTS IDENTIFIED BY (A) ON PAGE 60-12 AND ONE AT49552 RIGHT SEALING STRIP, AND ONE AT49553 LEFT SEALING STRIP) (SUB FOR AT35586)
...	AT75469	[1]	Cab	WITH NOISE REDUCTION
