约翰迪尔零件查询410 - BACKHOE, LOADER CAB BLOWER MOTOR AND HOUSING (SERIAL NO. -388073) [02B22]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
717 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
........
|
[1] |
Wheel
|
|
| 1. |
AN112782
|
[1] |
Wheel
|
|
| 2. |
22H1009
|
[2] |
Set Screw
|
|
| 3. |
........
|
[4] |
Ring
|
|
| 4. |
37H42
|
[12] |
Screw
|
|
| 5. |
........
|
[1] |
Bracket
|
|
| 6. |
24H1283
|
[4] |
Washer
|
|
| 7. |
AN112781
|
[1] |
Electric Motor
|
|
| 8. |
........
|
[1] |
Bracket
|
|
| 9. |
12H295
|
[8] |
Lock Washer
|
|
| 10. |
14H631
|
[8] |
Nut
|
|
| 11. |
........
|
[1] |
Housing
|
|
| 12. |
........
|
[1] |
Weatherstrip
|
|
| 13. |
12H302
|
[8] |
Lock Washer
|
|
| 14. |
14H786
|
[8] |
Nut
|
|
| ... |
AT35587
|
[1] |
Blower
|
|
