Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Cover	( AT35918 USE IF AVAILABLE)
2.	14H1000	[6]	Nut	0.112"
3.	AN112771	[1]	Switch
4.	12H313	[6]	Lock Washer	0.112"
5.	........	[1]	Holder	(AN112774 - NO LONGER AVAILABLE)
6.	21H1371	[2]	Screw	0.112" X 1/2"
7.	AH84167	[1]	Fuse	30 AMP, (SUB FOR AH15436)
8.	........	[1]	Wiring Lead	( AT35922 USE IF AVAILABLE)
9.	........	[1]	Grommet	( M16663 NO LONGER AVAIALBLE) (SUB FOR P40509)
10.	R21729	[32]	Washer
11.	........	[4]	Clip	(N114713 - NO LONGER AVAILABLE)
12.	21H1176	[4]	Screw	0.112" X 1/2"
13.	........	[2]	Louver	( AT35919 USE IF AVAILABLE)
14.	R44165	[1]	Lock Nut
15.	AR49969	[1]	Knob
16.	21H1302	[8]	Screw	1/4" X 5/8"
17.	19H1919	[3]	Cap Screw	1/4" X 5/8"
18.	12H302	[3]	Lock Washer	1/4"
19.	24H1285	[3]	Washer	17/64" X 7/16" X 0.065"
...	AT35587	[1]	Blower	(INCLUDES ALL PARTS ON THIS PAGE AND PAGE 60-13 PLUS ALL PARTS IDENTIFIED BY (B) ON PAGE 60-12) (ALSO ORDER AR40420 ALTERNATOR)
