约翰迪尔零件查询410 - BACKHOE, LOADER SEAT AND SEAT BELT [02C08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 230 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1648	[AR]	Cap Screw	3/8" X 3/4", (12 USED WITH SUSPENSION SEAT, 13 USED WITH REGULAR SEAT)
2.	T22782	[1]	Support	REAR (REGULAR SEAT)
3.	AT25964	[1]	Cushion	(BLACK)
4.	R81424	[1]	Safety Sign	(SUB FOR R42732)
5.	T27719	[1]	Support	L.H.
6.	AT20490	[1]	Cushion	(BLACK)
7.	R41778	[2]	Bolt	(A)
8.	24H1226	[4]	Washer	(A) 1/2" X 1-1/4" X 0.083"
9.	12H293	[1]	Lock Washer	(A) 7/16"
10.	14H813	[1]	Nut	(A) 7/16"
11.	24H1363	[2]	Washer	41/64" X 1-1/16" X 0.105"
12.	........	[1]	Seat Belt	(A) (SUB FOR AT24917) ( AT24149 NO LONGER AVAILABLE)
12.	AT37833	[1]	Seat Belt	(A) 76 MM (3") WIDE
12.	AT38518	[1]	Seat Belt	76MM (3") WIDE (COMPLIES WITH CALIFORNIA SAFETY CODE)
13.	T27718	[1]	Support
14.	14H1040	[2]	Nut	1/2", (SUB FOR 14H809)
15.	12H301	[2]	Lock Washer	1/2"
16.	T26153	[2]	Angle
17.	19H3579	[2]	Cap Screw	1/2" X 1-3/8"
...	........	[1]	Frame	( AT35687 NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS)
