约翰迪尔零件查询410 - BACKHOE, LOADER DELUXE SEAT SUPPORTS [02C09]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 792 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1765	[2]	Cap Screw	3/8" X 1-3/4"
2.	R27441	[10]	Washer
3.	19H3239	[4]	Cap Screw	3/8" X 1-1/4"
4.	R27116	[10]	Bushing
5.	14H819	[2]	Wing Nut	5/16", (SUB FOR T23238 AND R1069R)
6.	24H1290	[2]	Washer	21/64" X 3/4" X 0.035"
7.	F2863R	[8]	Snap Ring
8.	T21923	[2]	Shaft
9.	T23237	[1]	Support
10.	03H1540	[2]	Bolt	5/16" X 3/4"
11.	R1836R	[4]	Washer
12.	R26832	[4]	Bushing
13.	AR69854	[1]	Absorber	(SUB FOR AR26529)
14.	R27442	[1]	Cap	UPPER
15.	19H1648	[4]	Cap Screw	3/8" X 3/4"
16.	T21926	[2]	Bushing
17.	R26877	[1]	Spring
18.	R26879	[1]	Cap	LOWER
19.	14H812	[8]	Nut	3/8"
20.	19H2676	[1]	Cap Screw	3/8" X 1"
21.	T21920	[1]	Frame
22.	R72655	[2]	Snap Ring	(SUB FOR T12808)
23.	T21922	[1]	Pin Fastener
24.	T27971	[1]	Latch
25.	AT26122	[1]	Link
26.	........	[1]	Support	(SUB AT35094 AND T23227)
27.	R27440	[10]	Bushing
28.	19H2676	[2]	Cap Screw	3/8" X 1"
29.	M557T	[2]	Washer
30.	19H2898	[2]	Cap Screw	1/2" X 1-1/4"
31.	AT20438	[2]	Link	UPPER
32.	........	[1]	Link	( AT20441 NO LONGER AVAILABLE FOR SERVICE)
33.	24H1309	[2]	Washer	13/32" X 1-1/16" X 0.120"
