约翰迪尔零件查询410 - BACKHOE, LOADER FENDER SUPPORT AND STIFFENER (USE WITH RIGID MOUNT PLATFORM) [02C13]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 532 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2284	[6]	Cap Screw	3/8" X 7/8"
2.	19H2676	[6]	Cap Screw	3/8" X 1", (RIGHT FENDER)
2.	19H2676	[5]	Cap Screw	3/8" X 1", (LEFT FENDER)
3.	12H304	[12]	Lock Washer	3/8", (RIGHT FENDER)
3.	12H304	[11]	Lock Washer	3/8", (LEFT FENDER)
4.	24H1308	[10]	Washer	13/32" X 1" X 0.134"
5.	........	[1]	Reinforcement	( T34517 USE IF AVAILABLE) REAR
6.	19H2676	[1]	Cap Screw	3/8" X 1", (RIGHT FENDER)
7.	12H304	[1]	Lock Washer	3/8", (RIGHT FENDER)
8.	........	[1]	Support	( T34518 USE IF AVAILABLE)
9.	19H3239	[3]	Cap Screw	3/8" X 1-1/4", (LEFT FENDER)
10.	12H304	[3]	Lock Washer	3/8", (LEFT FENDER)
11.	24H1308	[1]	Washer	13/32" X 1" X 0.134", (LEFT FENDER)
12.	14H812	[6]	Nut	3/8"
13.	14H836	[4]	Nut	7/8"
14.	12H245	[4]	Lock Washer	7/8"
15.	08H4487	[4]	Cap Screw	7/8" X 9", (WITHOUT ROPS)
15.	08H4647	[1]	Cap Screw	7/8" X 13-1/2" (WITH ROPS)
16.	24H1309	[1]	Washer	13/32" X 1-1/16" X 0.120", (LEFT FENDER)
