| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT33407 | [2] | Rod | (172 AMPERE INSTALLATION) |
| 1. | AT33407 | [1] | Rod | (78 AMPERE INSTALLATION) |
| 2. | AT33408 | [1] | Clamp | (172 AMPERE INSTALLATION) |
| 2. | AT34995 | [1] | Clamp | (78 AMPERE INSTALLATION) |
| 3. | 14H786 | [2] | Nut | 1/4" |
| 4. | 24H1287 | [2] | Washer | 9/32" X 5/8" X 0.065" |
| 5. | ........ | [1] | Battery Box | ( AT33406 NO LONGER AVAILABLE) (SUB AT39534, T15511, (2) 14H786, (2) 24H1821 AND 03H2137) (FOR TRACTORS BUILT PRIOR TO SERIAL NO. 146710, ALSO ORDER ONE AT39633 BRAKE LINE KIT) (78 AMPERE INSTALLATION) |
| 5. | ........ | [1] | Battery Box | ( AT33406 NO LONGER AVAILABLE) (SUB AT39534, (2) T15511) (ALSO ORDER AT39633) (FOR TRACTORS BUILT PRIOR TO SERIAL NO. 146710, ALSO ORDER AT39633 BRAKE LINE KIT) (172 AMPERE INSTALLATION) |
| 6. | 12H304 | [3] | Lock Washer | 3/8" |
| 7. | 19H2676 | [3] | Cap Screw | 3/8" X 1" |
| 8. | 24H1307 | [AR] | Washer | 13/32" X 1" X 1/16" |
| 9. | 03H2137 | [1] | Bolt | 1/4" X 10-1/4", (78 AMPERE INSTALLATION) |
