| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 14H786 | [2] | Nut | 1/4" |
| 2. | 24H1287 | [2] | Washer | 9/32" X 5/8" X 0.065" |
| 3. | AT34995 | [1] | Clamp | (78 AMPERE INSTALLATION) |
| 3. | AT33408 | [1] | Clamp | (172 AMPERE INSTALLATION) |
| 4. | T15511 | [1] | Rod | (78 AMPERE INSTALLATION) |
| 4. | T15511 | [2] | Rod | (172 AMPERE INSTALLATION) |
| 5. | AT39534 | [1] | Battery Box | |
| 6. | 12H304 | [3] | Lock Washer | 3/8" |
| 7. | 19H2676 | [3] | Cap Screw | 3/8" X 1" |
| 8. | 03H2137 | [1] | Bolt | 1/4" X 10-1/4", (78 AMPERE INSTALLATION) |
| 9. | 24H1307 | [AR] | Washer | 13/32" X 1" X 1/16" |
