约翰迪尔零件查询410 - BACKHOE, LOADER REPLACEMENT STARTING MOTOR COIL ASSEMBLY, HOUSING AND ARMATURE (DIESEL) [02E18]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
785 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R81171
|
[2] |
Bolt
|
|
| 2. |
R81167
|
[1] |
End Plate
|
|
| 3. |
R61932
|
[1] |
Bushing
|
|
| 4. |
RE19189
|
[4] |
Screw
|
|
| 5. |
R81168
|
[4] |
Brush
|
|
| 6. |
R81169
|
[2] |
Carbon Brush Holder
|
|
| 7. |
R57028
|
[2] |
Wiring Lead
|
|
| 8. |
T736T
|
[2] |
Pin Fastener
|
|
| 9. |
AR68302
|
[2] |
Kit
|
|
| 10. |
RE19188
|
[1] |
Field Winding Coil
|
|
| 11. |
T11680
|
[4] |
Shoe
|
|
| 12. |
........
|
[1] |
Housing
|
|
| 13. |
21H1280
|
[8] |
Screw
|
|
| 14. |
R81173
|
[4] |
Dowel Pin
|
|
| 15. |
R81172
|
[1] |
Washer
|
|
| 16. |
RE19192
|
[1] |
Plate
|
|
| 17. |
R11236
|
[1] |
Grommet
|
|
| 18. |
AR68299
|
[1] |
Armature
|
|
| 19. |
R81198
|
[1] |
Thrust Washer
|
|
| 20. |
14H778
|
[4] |
Nut
|
|
| 21. |
12H246
|
[4] |
Lock Washer
|
|
| 22. |
21H1301
|
[4] |
Screw
|
|
| 23. |
R81170
|
[2] |
Spring
|
|
| 24. |
R57027
|
[2] |
Holder
|
|
| 25. |
R61934
|
[AR] |
Wick
|
|
| 26. |
........
|
[1] |
Motor
|
|
| 27. |
RE19191
|
[4] |
Screw With Washer
|
|
