约翰迪尔零件查询410 - BACKHOE, LOADER VOLTAGE REGULATOR AND ALTERNATOR ATTACHING PARTS [02E21]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询410 - BACKHOE, LOADER VOLTAGE REGULATOR AND ALTERNATOR ATTACHING PARTS [02E21]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 607 次

Pos.	Part No	Qty	Parts name	Comments
1.	R44008	[3]	Screw
2.	12H295	[3]	Lock Washer	0.190"
3.	AR78298	[1]	Voltage Regulator	(MOTOROLA NO. 8RF2014C) (SUB FOR AR38459 AND AR52927)
4.	R39804	[3]	Washer
5.	14H778	[2]	Nut	0.190"
6.	12H295	[3]	Lock Washer	0.190"
7.	AR38458	[1]	Alternator	35 AMP (MOTOROLA NO. A12NJD453) (WITHOUT PRESSURIZER)
7.	TY24306	[1]	Alternator	(SUB FOR TY1427) (35 AMPERE) (MOTOROLA) (REMANUFACTURED)
7.	AR40420	[1]	Alternator	55 AMP (MOTOROLA NO. A12NJD604) (WITH PRESSURIZER)
8.	19H2705	[1]	Cap Screw	5/16" X 1"
9.	12H303	[1]	Lock Washer	5/16"
10.	24H1136	[1]	Washer	11/32" X 11/16" X 0.065"
11.	R108404	[1]	Strap	(SUB FOR T20204 AND R107734)
12.	24H1304	[3]	Washer	13/32" X 23/32" X 0.120"
13.	12H304	[4]	Lock Washer	3/8"
14.	19H1726	[1]	Cap Screw	3/8" X 2-1/4"
15.	28H2547	[2]	Spacer	3/8" X 1"
16.	19H2458	[2]	Cap Screw	3/8" X 3"
17.	T20202	[1]	Bracket	FRONT
18.	19H2128	[1]	Cap Screw	3/8" X 3"
19.	12H297	[1]	Lock Washer	1/4"
20.	14H786	[1]	Nut	1/4"
21.	R38372	[1]	Bracket	REAR
22.	19H2284	[2]	Cap Screw	3/8" X 7/8"
23.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
24.	14H812	[1]	Nut	3/8"
25.	R122848	[1]	Shield	(SUB FOR R56012)
26.	24H1283	[2]	Washer	7/32" X 1/2" X .048"
