约翰迪尔零件查询410 - BACKHOE, LOADER ALTERNATOR (MOTOROLA NO. A12NJD453) (WITHOUT CAB) [02E22]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 832 次

Pos.	Part No	Qty	Parts name	Comments
1.	T23598	[4]	Screw
2.	14H778	[6]	Nut	0.190"
3.	12H295	[6]	Lock Washer	0.190"
4.	R15036	[4]	Washer
5.	37H10	[2]	Screw	NO. 8 X 3/8"
6.	R15026	[1]	Brush
7.	12H297	[1]	Lock Washer	1/4"
8.	14H786	[1]	Nut	1/4"
9.	R15036	[2]	Washer
10.	R39803	[1]	Washer
11.	R39800	[1]	Diode	SINGLE, (SUB FOR AR38461)
12.	R38374	[1]	Housing	REAR
13.	R15035	[2]	Sleeve
14.	R15030	[1]	O-Ring	REAR BEARING
15.	R15023	[1]	Diode	POSITIVE
16.	........	[1]	Stator	( AT21161 USE IF AVAILABLE)
17.	R15024	[1]	Diode	NEGATIVE
18.	14H866	[1]	Nut	5/8"
19.	12H294	[1]	Lock Washer	5/8"
20.	T24474	[1]	Pulley
21.	R15027	[1]	Fan
22.	........	[1]	Bushing	( T25343 USE IF AVAILABLE)
23.	T23610	[4]	Nut
24.	R15033	[1]	Housing	FRONT
25.	JD9449	[1]	Ball Bearing	FRONT, (SUB FOR AT23188)
26.	R15029	[1]	Retainer	FRONT BEARING
27.	26H9	[1]	Shaft Key	1/8" X 5/8"
28.	........	[1]	Rotor	( AT21160 USE IF AVAILABLE)
29.	AT23189	[1]	Ball Bearing	REAR
...	AR38458	[1]	Alternator	(12 VOLT) (35 AMP)
...	TY24306	[1]	Alternator	(SUB FOR TY1427) (35 AMPERE) (MOTOROLA) (REMANUFACTURED)
