| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | R131794 | [1] | Gasket | CYLINDER BLOCK PLATE, (SUB FOR T24965 AND R73140, THIS APPLICATION) (SUB FOR R90648) |
| 2. | R49516 | [1] | Gasket | FLYWHEEL HOUSING (USE IF AVAILABLE) |
| 2. | R97351 | [1] | Gasket | (SUB FOR R49516) |
| 3. | R48768 | [4] | Washer | CYLINDER LINER |
| 4. | T20304 | [1] | Washer | TACHOMETER DRIVE SHAFT |
| 5. | T13213 | [1] | Washer | ALUMINUM, OIL DRAIN PLUG |
| 6. | R74354 | [1] | O-Ring | OIL PUMP OUTLET TUBE (SUB FOR R27166, THIS APPLICATION) |
| 7. | R56463 | [1] | O-Ring | VENT TUBE (SUB FOR R495R, THIS APPLICATION) |
| 8. | T20328 | [1] | Gasket | OIL FILTER CAP |
| 9. | R73521 | [1] | Gasket | (ALSO ORDER (8) AR103811) (SUB FOR T20075 AND AR100596) |
| 10. | R125863 | [1] | Gasket | CYLINDER HEAD, (SUB FOR R59448, R80242 AND R91878 OR R92425) |
| 11. | R81275 | [1] | Gasket | AIR INLET, (SUB FOR T20159, THIS APPLICATION) |
| 12. | T20219 | [1] | Gasket | THERMOSTAT HOUSING |
| 13. | R121314 | [1] | Gasket | TIMING GEAR COVER, (SUB FOR T20155 OR R97454 OR R119269) |
| 14. | R97342 | [1] | Gasket | OIL PAN, (SUB FOR R49515) |
| 15. | T20364 | [1] | Gasket | INJECTION PUMP GEAR COVER, (SUB R78366) |
| 15. | R125066 | [1] | Gasket | INJECTION PUMP GEAR COVER, (SUB FOR R69260 AND R78366 OR R97773) |
| 16. | R90658 | [4] | Gasket | EXHAUST MANIFOLD, (SUB FOR T20006) (ALL T20006 GASKETS MUST BE REPLACED AT THE SAME TIME. DO NOT MIX T20006 AND R90658) |
| 17. | R520618 | [1] | Gasket | FUEL PUMP, (SUB FOR R97350, R27285) |
| 18. | T20215 | [1] | Gasket | THERMOSTAT COVER |
| 19. | R70956 | [1] | Washer | (SUB FOR R55434) OIL COOLER |
| 20. | T20243 | [1] | Gasket | WATER PUMP COVER |
| 21. | T20273 | [1] | Gasket | TIMING GEAR COVER OPENING COVER |
| 22. | T20336 | [1] | Gasket | OIL FILTER INLET |
| 23. | RE16922 | [1] | Gasket Kit | (SUB FOR RE12459) (USE IF AVAILABLE) (ALSO ORDER (4) AR71618, (8) AR103811, (4) R48000 AND (4) RE32011) |
| 23. | RE501579 | [1] | Gasket Kit | (SUB FOR RE38857) (ALSO ORDER (4) AR71618, (8) AR103811, (4) R48000 AND (4) RE32011) |
