约翰迪尔零件查询410 - BACKHOE, LOADER ENGINE OVERHAUL GASKET SET (GASOLINE) (SERIAL NO. -192000) [02F08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 1013 次

Pos.	Part No	Qty	Parts name	Comments
1.	R131794	[1]	Gasket	(SUB FOR R90648)
2.	T20154	[1]	Gasket	TIMING GEAR COVER
3.	T20328	[1]	Gasket	OIL FILLER CAP
4.	T20112	[1]	Gasket	DISTRIBUTOR
5.	T20304	[1]	Washer	TACHOMETER DRIVE SHAFT
6.	T13213	[1]	Washer	ALUMINUM, OIL DRAIN PLUG
7.	R56463	[1]	O-Ring	VENT TUBE OUTLET (SUB FOR R495R, THIS APPLICATION)
8.	R74354	[1]	O-Ring	OIL PUMP OUTLET TUBE (SUB FOR R27166, THIS APPLICATION)
9.	R87627	[4]	O-Ring	INTAKE VALVES, (SUB FOR R27976)
10.	AR100596	[1]	Gasket	ROCKER ARM COVER, (SUB FOR T20075) (ALSO ORDER (8) AR103811 CAP SCREWS WITH WASHERS)
11.	R98836	[1]	Gasket	(SUB FOR T20207) ENGINE MANIFOLD
12.	R98461	[1]	Engine Cylinder Head Gasket	CYLINDER HEAD, (SUB FOR T20040 AND R52790)
13.	R49516	[1]	Gasket	FLYWHEEL HOUSING (USE IF AVAILABLE)
13.	R97351	[1]	Gasket	(SUB FOR R49516)
14.	T20232	[1]	Washer	GOVERNOR HOUSING
15.	T20239	[1]	Gasket	WATER PUMP COVER
16.	R119360	[1]	Gasket	(SUB FOR T24535) OIL PAN
17.	T10079	[1]	Gasket	(USE IF AVAILABLE) (SUB R98821) CARBURETOR
17.	R98821	[1]	Gasket	(SUB FOR T10079)
18.	R520618	[1]	Gasket	FUEL PUMP, (SUB FOR R97350, R27285)
19.	T20208	[1]	Gasket	(USE IF AVAILABALE) (SUB R98837) EXHAUST MANIFOLD
19.	R98837	[1]	Gasket	(SUB FOR T20208)
20.	T20212	[1]	Gasket	THERMOSTAT HOUSING
21.	T20215	[1]	Gasket	THERMOSTAT COVER
22.	R97352	[1]	Gasket	(SUB FOR T20336) OIL FILLER INLET
23.	T20273	[1]	Gasket	TIMING GEAR COVER OPENING COVER
...	RE501582	[1]	Gasket Kit	(SUB FOR RE40429) (ALSO ORDER (4) AR71617 AND (8) AR103811)
