| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U44449 | [1] | Rod | |
| 2. | 19H2284 | [2] | Cap Screw | 3/8" X 7/8" |
| 3. | 12H304 | [2] | Lock Washer | 3/8" |
| 4. | S86186 | [1] | Decals | (A) 4-IN-1 TILT |
| 5. | S506318 | [1] | Gauge | (A) |
| 6. | 14H813 | [2] | Nut | 7/16" |
| 7. | AT32956 | [1] | Pivot |
广数供应链运营团队, 16 02月, 2025，浏览： 612 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U44449 | [1] | Rod | |
| 2. | 19H2284 | [2] | Cap Screw | 3/8" X 7/8" |
| 3. | 12H304 | [2] | Lock Washer | 3/8" |
| 4. | S86186 | [1] | Decals | (A) 4-IN-1 TILT |
| 5. | S506318 | [1] | Gauge | (A) |
| 6. | 14H813 | [2] | Nut | 7/16" |
| 7. | AT32956 | [1] | Pivot |
