约翰迪尔零件查询410 - BACKHOE, LOADER LOADER BUCKET LINKAGE [02G01]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
1010 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
11H223
|
[2] |
Cotter Pin
|
|
| 2. |
24H1540
|
[2] |
Washer
|
|
| 3. |
T31904
|
[2] |
Pin
|
|
| 4. |
19H1912
|
[6] |
Cap Screw
|
|
| 5. |
T11234
|
[6] |
Lock Nut
|
|
| 6. |
AT32892
|
[1] |
Link
|
|
| 6. |
AT37498
|
[1] |
Link
|
|
| 7. |
U11121
|
[2] |
Bushing
|
|
| 8. |
AT32895
|
[2] |
Link
|
|
| 9. |
AT32893
|
[1] |
Link
|
|
| 9. |
AT37499
|
[1] |
Link
|
|
| 10. |
T33776
|
[2] |
Pin
|
|
| 11A. |
U17031
|
[2] |
Bushing
|
|
| 11B. |
T34259
|
[4] |
Bushing
|
|
| 12. |
T162396
|
[2] |
Lubrication Fitting
|
|
| 13. |
T38678
|
[4] |
Pin Fastener
|
|
| 14. |
24H1542
|
[AR] |
Washer
|
|
| 15. |
U16068
|
[8] |
Snap Ring
|
|
