约翰迪尔零件查询410 - BACKHOE, LOADER LOADER BOOM CYLINDER [02G18]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
335 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
JD7799
|
[2] |
Lubrication Fitting
|
|
| 2. |
U42424
|
[2] |
Bushing
|
|
| 3. |
AT33341
|
[1] |
Hydraulic Cylinder
|
|
| 4. |
U13572
|
[1] |
Lock Nut
|
|
| 5. |
U42863
|
[1] |
Wear Ring
|
|
| 6. |
T34321
|
[1] |
Piston
|
|
| 7. |
T54808
|
[1] |
Packing
|
|
| 8. |
A3606R
|
[1] |
O-Ring
|
|
| 9. |
T34319
|
[1] |
Piston
|
|
| 10. |
U14128
|
[1] |
Snap Ring
|
|
| 11. |
R76802
|
[1] |
Seal
|
|
| 12. |
U41823
|
[1] |
Wear Ring
|
|
| 13. |
T34317
|
[1] |
Hydr. Cylinder Rod Guide
|
|
| 14. |
M4237T
|
[1] |
O-Ring
|
|
| 15. |
T19829
|
[1] |
Back-Up Ring
|
|
| 16. |
T34318
|
[1] |
Snap Ring
|
|
| 17. |
U16406
|
[1] |
Seal
|
|
| 18. |
T34316
|
[1] |
Nut
|
|
| 19. |
T34259
|
[2] |
Bushing
|
|
| 20. |
AT33339
|
[1] |
Rod
|
|
| ... |
AT33026
|
[1] |
Hydraulic Cylinder
|
|
| ... |
AR105402
|
[1] |
Hydraulic Cylinder Kit
|
|
