约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE MAIN FRAME AND TIE BARS [02G22]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 723 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1912	[2]	Cap Screw	3/8" X 3-1/2"
2.	T35610	[2]	Strap
3A.	T33686	[1]	Platform	(SUB T44568)
3B.	T44568	[1]	Platform
4.	19H2676	[2]	Cap Screw	3/8" X 1"
5.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
6.	19H2599	[8]	Cap Screw	5/8" X 2-1/2"
7.	12H294	[8]	Lock Washer	5/8"
8.	U43436	[4]	Strap
9.	U43435	[4]	Tapered Sleeve	OUTER
10.	U43433	[4]	Pin Fastener
11.	T34301	[4]	Bushing
12.	AT32826	[1]	Main Frame
13.	U43434	[4]	Sleeve	INNER
14.	U43490	[2]	Pin
15.	BP12214	[2]	Lock Nut	1/2", (SUB FOR U12622)
16.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
17.	19H3520	[2]	Cap Screw	1/2" X 3-1/4"
18.	T34559	[2]	Pin Fastener	STABILIZER CYLINDER (HEAD END)
19.	T11234	[2]	Lock Nut	3/8"
20.	T33715	[2]	Pin Fastener
21A.	T33714	[1]	Pin Fastener	(SUB T40639 AND (2) U16068)
21B.	T40639	[2]	Groove Pin
22.	T35537	[2]	Plate	(WITHOUT CAB)
23.	19H1648	[4]	Cap Screw	3/8" X 3/4", (WITHOUT CAB)
24.	12H304	[4]	Lock Washer	3/8", (WITHOUT CAB)
25.	U16068	[4]	Snap Ring
26.	19H1912	[2]	Cap Screw	3/8" X 3-1/2"
27.	T11234	[2]	Lock Nut	3/8"
28.	T45626	[1]	Pad
