约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE SWING FRAME [02H02]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 956 次

Pos.	Part No	Qty	Parts name	Comments
1.	A3581R	[1]	Spring Locking Pin	(SUB FOR 34H321)
2.	T68041	[1]	Pin Fastener	(SUB FOR U41722)
3.	08H4308	[2]	Cap Screw	3/4" X 8"
4.	U43442	[4]	Washer
5.	U43435	[2]	Tapered Sleeve	OUTER
6.	T35016	[2]	Spacer	PIVOT PIN
7.	U41086	[2]	Bushing	(A)
8.	19H2211	[1]	Cap Screw	1/2" X 5"
9.	T33685	[1]	Pin
10.	BP12214	[1]	Lock Nut	(SUB FOR U12622)
11.	AT32825	[1]	Frame	(E) (INCLUDES PARTS IDENTIFIED BY (A) (SUB AT64769)
11.	AT64769	[1]	Frame	(E) (INCLUDES PARTS IDENTIFIED BY (A)
12.	T33689	[2]	Bushing	(A)
13.	JD7788	[2]	Lubrication Fitting	1/4"
14.	JD7797	[6]	Lubrication Fitting	(A) 1/4", STRAIGHT
15.	T67205	[2]	Thrust Washer	(SUB FOR U41077)
16.	T55322	[2]	Tapered Sleeve	(SUB FOR T34188)
17.	U11649	[4]	Washer	(B)
18.	T33688	[2]	Bushing	(A)
19A.	T33690	[1]	Pin Fastener	(B) (SUB T37598 AND (2) 11H221)
19A.	T37598	[2]	Pin	(B)
19B.	T59453	[2]	Groove Pin	(B) (E) (SUB T37598, (2) U11649 AND (2) 11H221, THIS APPLICATION)
19C.	T37598	[2]	Pin	(E)
20.	11M7085	[4]	Cotter Pin	(B) 6.300 X 63 MM
20.	11H221	[4]	Cotter Pin	(B) 3/8" X 2-1/2"
21.	T25879	[2]	Nut
22.	T59452	[4]	Snap Ring	(B) (E)
23.	U11649	[4]	Washer	(E)
24.	11H221	[4]	Cotter Pin	(E) 3/8" X 2-1/2"
