Pos.	Part No	Qty	Parts name	Comments
1.	U11004	[6]	Pin Fastener
2.	11M7079	[6]	Cotter Pin	2.500 X 12 MM
3.	T53969	[2]	Link
4.	34H391	[2]	Spring Pin	5/16" X 15/16"
5.	11M7083	[2]	Cotter Pin	3.200 X 50 MM
6.	T53976	[2]	Support	(SUB FOR U15803)
7.	14H826	[2]	Nut	1/2"
8.	U43216	[2]	Lever
9.	U43703	[4]	Grip
10.	AT51881	[4]	Link	FOUR-WAY LEVER
11.	T53971	[2]	Link
12.	25H830	[2]	Groove Pin	3/8" X 2"
13.	19H1849	[2]	Cap Screw	5/16" X 1-1/4"
14.	U13489	[2]	Washer
15.	14H1039	[2]	Nut	5/8", (SUB FOR U14555, THIS APPLICATION)
16.	H143332	[4]	Lock Nut	(SUB FOR T32688)
17.	U43214	[2]	Lever	FOUR-WAY LEVER
18.	T53973	[1]	Pivot	L.H.
19.	T53972	[1]	Pivot	R.H.
20.	19H2569	[2]	Cap Screw	5/16" X 1-5/8"
21.	T53970	[1]	Support
22.	U16010	[2]	Pin Fastener
23.	12H304	[4]	Lock Washer	3/8"
24.	14H812	[4]	Nut	3/8"
25.	T53977	[4]	Snap Ring
26.	24H1274	[6]	Washer	49/64" X 1-1/4" X 0.048"
27.	T53974	[2]	Pin Fastener	FOUR-WAY LEVER
28.	03H1480	[4]	Bolt	3/8" X 1-1/4"
29.	24H1305	[4]	Washer	13/32" X 13/16" X 0.065"
30.	AT50177	[1]	Pedal
