约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE VALVE BOX AND COVER [02H07]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
469 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H2472
|
[3] |
Cap Screw
|
|
| 2. |
12H301
|
[3] |
Lock Washer
|
|
| 3. |
03H1480
|
[4] |
Bolt
|
|
| 4. |
24H1305
|
[4] |
Washer
|
|
| 5. |
12H304
|
[10] |
Lock Washer
|
|
| 6. |
14H812
|
[10] |
Nut
|
|
| 7. |
AT32812
|
[1] |
Box
|
|
| 8. |
T33683
|
[1] |
Valve Cover
|
|
| 9. |
T33684
|
[1] |
Valve Cover
|
|
| 10. |
24H1287
|
[6] |
Washer
|
|
| 11. |
12H302
|
[6] |
Lock Washer
|
|
| 12. |
19H1227
|
[6] |
Cap Screw
|
|
| 13. |
19H2676
|
[6] |
Cap Screw
|
|
| 14. |
T122182
|
[1] |
Bracket
|
|
| 15. |
24H1652
|
[2] |
Washer
|
|
| 16. |
T135327
|
[1] |
Isolator
|
|
| 17. |
T51220
|
[1] |
Isolator
|
|
