Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Relief Valve	(SUB AT34823 OR AU40529)
2.	32240	[1]	O-Ring
3.	........	[1]	Guide	(SUB AT34823 OR AU40529)
4.	........	[AR]	Shim	.25 MM (.010") (SUB AT34823 OR AU40529)
4.	........	[AR]	Shim	.38 MM (.015") (SUB AT34823 OR AU40529)
4.	........	[AR]	Shim	.76 MM (.030") (SUB AT34823 OR AU40529)
4.	........	[AR]	Shim	1.5 MM (.058") (SUB AT34823 OR AU40529) (SUB FOR R43549, THIS APPLICATION)
5.	........	[1]	Spring	164 BAR, 241 BAR (FOR 2375 PSI, 3500 PSI) (SUB AT34823 OR AU40529) (SUB FOR U40738, THIS APPLICATION)
6.	........	[1]	Seat	(SUB AT34823 OR AU40529)
7.	T68668	[1]	Washer	(SUB FOR H61397, THIS APPLICATION)
8.	R87627	[1]	O-Ring	(SUB FOR R27976, THIS APPLICATION)
9.	U40745	[1]	O-Ring
10.	........	[1]	Plug	(SUB AT34823 OR AU40529)
11.	........	[1]	Retainer	(SUB AT34823 OR AU40529)
12.	........	[1]	Snap Ring	(SUB AT34823 OR AU40529) (SUB FOR R31415, THIS APPLICATION)
...	AU40529	[1]	Pressure Relief Valve	164 BAR (2375 PSI)
...	AT34823	[1]	Pressure Relief Valve	241 BAR (3500 PSI)
