约翰迪尔零件查询410 - BACKHOE, LOADER OIL LINES AND FITTINGS (BACKHOE STABILIZER AND SWING CIRCUIT) (SERIAL NO. 025415- ) [02H19]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 211 次

Pos.	Part No	Qty	Parts name	Comments
1.	R26906	[6]	O-Ring
2.	AW10635	[4]	Elbow Fitting
3.	AU42638	[1]	Adapter Fitting
4.	AU11582	[1]	Adapter Fitting
5.	AT50017	[4]	Hydraulic Hose - Fabricate	1 360 MM (3/8" X 53-1/2" LONG) (SUB FOR AU41203)
6.	R26375	[4]	O-Ring	(SUB FOR U10778)
7.	AU13611	[2]	Elbow Fitting
8.	R26448	[2]	O-Ring
9.	AU11669	[2]	Elbow Fitting
10.	R26375	[2]	O-Ring
11.	AT36179	[2]	Adapter Fitting
12.	19H1648	[2]	Cap Screw	3/8" X 3/4", (USE WITH HEAD END CYLINDER HOSE)
12.	19H3483	[2]	Cap Screw	3/8" X 1-1/8", (USE WITH ROD END CYLINDER HOSE)
13.	12H304	[4]	Lock Washer	3/8"
14.	T24959	[4]	Clamp
15.	AU12083	[1]	Hydraulic Hose - Fabricate	660 MM (3/8" X 26" LONG) (SUB FOR AT32809)
16.	AW12255	[1]	Hydraulic Hose	813 MM (3/8" X 32" LONG)
17.	AU40691	[1]	Hydraulic Hose - Fabricate	(SUB FOR AT36736) 610 MM (3/8" X 24" LONG)
18.	AT36095	[1]	Hydraulic Hose - Fabricate	(SUB FOR AT36737) 660 MM (3/8" X 26" LONG)
19.	24H1305	[4]	Washer	13/32" X 13/16" X 0.065"
20.	AU11569	[2]	Adapter Fitting
21.	14H812	[2]	Nut	3/8", (USE WITH ROD END CYLINDER HOSE)
22.	JD174	[2]	Elbow Fitting
