约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE STABILIZER CYLINDER (BACKHOE SERIAL NO. 025415- ) [02H25]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
300 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U11121
|
[2] |
Bushing
|
|
| 1. |
R92851
|
[2] |
Bushing
|
|
| 2. |
U13572
|
[1] |
Lock Nut
|
|
| 3. |
U17217
|
[1] |
Wear Ring
|
|
| 4. |
U17349
|
[1] |
Piston
|
|
| 5. |
T38193
|
[1] |
Packing
|
|
| 6. |
A3606R
|
[1] |
O-Ring
|
|
| 7. |
U17345
|
[1] |
Piston
|
|
| 8. |
U14128
|
[1] |
Snap Ring
|
|
| 9. |
R76802
|
[1] |
Seal
|
|
| 10. |
U41823
|
[1] |
Wear Ring
|
|
| 11. |
U41897
|
[1] |
Guide
|
|
| 12. |
U10776
|
[1] |
O-Ring
|
|
| 13. |
R78993
|
[1] |
Back-Up Ring
|
|
| 14. |
U10775
|
[1] |
Snap Ring
|
|
| 15. |
U11019
|
[1] |
Seal
|
|
| 16. |
U10769
|
[1] |
Nut
|
|
| 17. |
U11121
|
[2] |
Bushing
|
|
| 18. |
AT34992
|
[1] |
Hydraulic Cylinder Rod
|
|
| 19. |
RE32619
|
[1] |
Hydraulic Cylinder Barrel
|
|
| 20. |
T12844
|
[2] |
Reinforcement
|
|
| 21. |
AT45903
|
[2] |
Cylinder
|
|
| ... |
RE18754
|
[1] |
Hydraulic Cylinder Kit
|
|
