约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE STABILIZER CYLINDER (BACKHOE SERIAL NO. -025414) [02H24]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 213 次

Pos.	Part No	Qty	Parts name	Comments
1.	U11121	[2]	Bushing
2.	AT34991	[1]	Hydraulic Cylinder Barrel
3.	R26375	[1]	O-Ring
4.	A3917R	[1]	O-Ring
5.	U42982	[1]	Back-Up Ring
6.	U42980	[1]	Sleeve
7.	U42979	[1]	Fitting
8.	AU42034	[1]	Adapter Fitting
9.	AU42267	[1]	Tube
10.	R26375	[1]	O-Ring	(SUB FOR U10778)
11.	AU11569	[1]	Adapter Fitting
12.	U13572	[1]	Lock Nut
13.	U17217	[1]	Wear Ring	(A)
14.	U17349	[1]	Piston
15.	T38193	[1]	Packing	(A) (SUB FOR U12967, THIS APPLICATION) (SUB FOR R72827)
16.	A3606R	[1]	O-Ring	(A)
17.	U17345	[1]	Piston
18.	U14128	[1]	Snap Ring
19.	R76802	[1]	Seal	(A) (SUB FOR T36998)
20.	U41823	[1]	Wear Ring	(A)
21.	U41897	[1]	Hydr. Cylinder Rod Guide
22.	U10776	[1]	O-Ring	(A)
23.	R78993	[1]	Back-Up Ring	(A) (SUB FOR U10777, THIS APPLICATION)
24.	U10775	[1]	Snap Ring
25.	U11019	[1]	Seal	(A)
26.	U10769	[1]	Nut
27.	U11121	[2]	Bushing
28.	AT34992	[1]	Hydraulic Cylinder Rod
...	AT34990	[2]	Hydraulic Cylinder
...	RE18754	[1]	Hydraulic Cylinder Kit	(SUB FOR AU41405, AT36836, AT52703, AR96518 AND AR105407)
