约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE BOOM CYLINDER [02I14]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 757 次

Pos.	Part No	Qty	Parts name	Comments
1.	T33669	[1]	Bushing
2.	AT32791	[1]	Hydraulic Cylinder Barrel
3.	JD7759	[2]	Lubrication Fitting	1/8", STRAIGHT
4.	U44332	[2]	Bushing
5.	22H842	[1]	Set Screw	1/4" X 5/16"
6.	U10750	[1]	Lock Nut
7.	U45231	[1]	Piston Ring
8.	T33663	[1]	Piston
9.	U17225	[1]	Wear Ring	(A)
10.	U17346	[1]	Piston
11.	U10289	[1]	O-Ring	(A)
12.	T37379	[1]	Packing	(A) (SUB FOR U12974, THIS APPLICATION) (SUB FOR R72828)
13.	U10746	[1]	O-Ring	(A)
13.	P46765	[1]	O-Ring	(A)
14.	U10748	[1]	Back-Up Ring	(A)
14.	R79001	[1]	Back-Up Ring	(A) (SUB FOR T42552, THIS APPLICATION)
15.	W11229	[1]	Ring
16.	R76790	[1]	Packing	(A) (SUB FOR T35851)
17.	U42716	[1]	Wear Ring	(A)
18.	U43378	[1]	Guide	(SUB P46765, R79001 AND R80944)
18.	R80944	[1]	Guide	(SUB FOR T57009)
19.	U11022	[1]	Seal	(A)
20.	AT32793	[1]	Hydraulic Cylinder Rod
...	AT32790	[1]	Hydraulic Cylinder	(SUB RE12725)
...	AR105355	[1]	Hydraulic Cylinder Kit	REPAIR, (SUB FOR AT35936, AT36832, AT55691 AND AR99791)
