约翰迪尔零件查询410 - BACKHOE, LOADER REPLACEMENT BACKHOE SWING CYLINDER [02I13]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 740 次

Pos.	Part No	Qty	Parts name	Comments
1.	R81342	[1]	Hydraulic Cylinder Cap	(SUB FOR U43461)
2.	L2309CU	[1]	Back-Up Ring
3.	L2301CU	[1]	O-Ring
4.	22H1077	[2]	Set Screw	1/4" X 5/16"
5.	U43454	[2]	Bushing
6.	AR104410	[1]	Hydraulic Cylinder Barrel
7.	T162396	[2]	Lubrication Fitting	(SUB FOR JD7798)
8.	L2235CU	[1]	Lock Nut
9.	U44491	[1]	Piston Ring
10.	T37360	[1]	Piston	OUTER
11.	U17337	[1]	Wear Ring	(K)
12.	R77819	[2]	Back-Up Ring
13.	R77820	[1]	Seal
14.	R77818	[1]	Seal
15.	RE11904	[1]	Seal	(K)
16.	R78389	[2]	Washer	(K)
17.	R29463	[1]	O-Ring	(K)
18.	T37381	[1]	Packing
19.	R77809	[1]	Piston	INNER
20.	A5598R	[1]	O-Ring	(K)
21.	R79122	[1]	Back-Up Ring	(K) (SUB FOR T42032, THIS APPLICATION)
22.	N10193	[1]	Snap Ring
23.	R76801	[1]	Packing	(K)
24.	U41578	[1]	Wear Ring	(K)
25.	R80937	[1]	Hydr. Cylinder Rod Guide	(SUB FOR T57011)
26.	L2029CU	[1]	Seal	(K)
27.	JD7797	[1]	Lubrication Fitting
28.	T33708	[1]	Bushing
29.	AT56434	[1]	Hydraulic Cylinder Rod
30.	RE12723	[1]	Hydraulic Cylinder
