约翰迪尔零件查询410B - BACKHOE, LOADER RIGHT-HAND SIDE COWL COVERS [02G20]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
351 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT73951
|
[1] |
Support
|
|
| 1. |
AT67942
|
[1] |
Support
|
|
| 2. |
........
|
[1] |
Weatherstrip
|
|
| 3. |
AT101245
|
[1] |
Cover
|
|
| 4. |
T70574
|
[1] |
U-Bolt
|
|
| 5. |
14M7165
|
[4] |
Lock Nut
|
|
| 6. |
24M7207
|
[6] |
Washer
|
|
| 7. |
19M7865
|
[2] |
Screw
|
|
| 8. |
AT101542
|
[1] |
Cover
|
|
| 9. |
19M7560
|
[4] |
Cap Screw
|
|
| 10. |
T69610
|
[1] |
Cover
|
|
| 11. |
19M7865
|
[2] |
Screw
|
|
| 12. |
24M7040
|
[2] |
Washer
|
|
| 13. |
19M6755
|
[1] |
Cap Screw
|
|
| 14. |
24H1287
|
[2] |
Washer
|
|
| 15. |
T12093
|
[1] |
Strap
|
|
| 16. |
24H1287
|
[AR] |
Washer
|
|
| 17. |
19M7775
|
[2] |
Screw
|
|
| 18. |
R67195
|
[1] |
Strap
|
|
| 19. |
........
|
[1] |
Weatherstrip
|
|
| 20. |
........
|
[1] |
Isolator
|
|
| 21. |
M84972
|
[2] |
Nut
|
|
