Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Main Frame	(SUB AT135890 OR AT101079)
2.	JD7799	[2]	Lubrication Fitting	(SUB FOR JD7781, JD7763 AND JD7847, THIS APPLICATION)
3.	AT36635	[1]	Bumper
4.	T76893	[1]	Bracket
5.	24H1822	[1]	Washer	11/32" X 7/8" X 1/16"
6.	14H650	[1]	Nut	5/16"
7.	19M7784	[1]	Screw	M10 X 20
8.	T118732	[1]	Barrier	(SUB FOR T100643)
9.	24M7296	[4]	Washer	10.500 X 30 X 2.500 MM
10.	19M7166	[4]	Cap Screw	M10 X 20
11.	T83420	[2]	Deflector	( T83420 USE IF AVAILABLE)
12.	24M7028	[4]	Washer	10.500 X 20 X 2 MM
12.	T106383	[4]	Strap	(NOT ILLUSTRATED)
13.	19M7938	[4]	Cap Screw	M10 X 20
14.	........	[1]	Pipe	(NOT REQUIRED)
15.	........	[1]	Cap Screw	(NOT REQUIRED)
16.	B5977H	[2]	Washer
17.	14M7296	[1]	Flange Nut	M10
18.	T69146	[2]	Bushing
19.	40M7166	[2]	Snap Ring
20.	T100317	[2]	Pin
21.	T76308	[2]	Bushing	BOOM PIVOT
22.	........	[1]	Deflector	( AT85773 NO LONGER AVAILABLE)
23.	AT66209	[1]	Main Frame	(SUB AT135890 AND AT101642)
23.	........	[1]	Main Frame	( AT100697, NO LONGER AVAILABLE) (SUB AT135890)
23.	........	[1]	Main Frame	( AT135890 NO LONGER AVAILABLE) (NOT ILLUSTRATED)
23.	AT101642	[1]	Kit	(NOT ILLUSTRATED)
